Tenda A9 - Wireless N300 2.4GHz 300Mbps Universal Range Extender with WPS Button
Available to Order
- Stock: Tenda Backorder
- Brand: Tenda
- Model: A9
- Weight: 0.22kg
- EAN: 6932849427325
- MPN: TENDA-A9
The Tenda A9 is a Wi-Fi range extender that you can use to quickly and easily increase the signal coverage of your existing Wi-Fi network. A9 is a 2.4GHz wireless N300 extender that could reach a speed of up to 300Mbps, which is fast enough to enjoy buffer-free HD Movie streaming, lag-free online gaming, and non-stop file sharing. It has a sleek wall-mount design that you can easily plug into any wall outlet in your house. Added to that is a smart LED light indicator for signal and device statuses like; booting, strong/weak signal, or success signal expansion.
The A9 acts as a Wi-Fi client and access point at the same time. It connects to an existing WiFi access point as a client and also functions as an Access Point, thereby extending the existing wireless signal to other corners/rooms of your home.
To know more about the A9 wireless expander, please read the technical specification section.
A9 vs. A301: Quick Comparison Table
| A9 | A301 | |
| Frequency Band | 2.4GHz | 2.4GHz |
| Data Rate | 802.11b: 11Mbps 802.11g: 54Mbps 802.11n: 300Mbps |
802.11b: 11Mbps 802.11g: 54Mbps 802.11n: 300Mbps |
| Antenna (non-detachable) | 2 x External 3dBi omnidirectional | 2 x External 3dBi omnidirectional |
| Theoretical Coverage | 150 square meters | 150 square meters |
| Operating Mode | Repeater Mode Only |
Repeater Mode AP Mode |
Main Features
- 300Mbps 802.11n Speed (802.11b/g compatible)
- 2 x 3dBi Smart External Omni-Directional Antennas - Lets You Extend WiFi coverage up to 200㎡
- WPS Button For Quick Client Connection
- Smart WiFi Signal Strength LED Indicator (helps you choose the optimum location easily)
- Compatible with the Following Encryption Protocols; WPA-PSK, WPA2-PSK and Mixed WPA/WPA2-PSK
- Supports Hidden SSID
Technical Specification
| Hardware | |
| Port | None |
| Button | Reset / WPS |
| LED Indicator | 1 x Signal Strength Indicator |
| Chipset | RTL8196ER + RTL8192ER |
| RAM | 8MB |
| Power | Internal 3.3V 1A Power |
| Plug | China, USA, EU, UK |
| Rated Voltage/Frequency/Current | 100-240V 50/60Hz, 0.3A Max, CLASS II |
| Dimension | |
| Unit Dimensions | 111 x 56 x 47.7mm |
| Environment | |
| Operating Temperature | 0°C~40°C |
| Storage Temperature | -40~70°C |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 05%~90% non-condensing |
| Wireless | |
| Standard | IEEE802.11b, IEEE 802.11g, IEEE 802.11n |
| Modulation | 802.11b: DSSS / BPSK / QPSK / CCK |
| 802.11g: OFDM / DSSS / BPSK / QPSK / CCK | |
| 802.11n: OFDM / DSSS / BPSK / QPSK / CCK | |
| Transmission Speed | 802.11b (11 Mbps) |
|
|
802.11g (54 Mbps) |
|
|
802.11n (300 Mbps) |
| Frequency | 2.412~2.484 GHz |
| Antenna | 2 x 3dBi external antenna non-detachable |
| Coverage | 150m 2 |
| Wireless Security | Encryption Mode: Mix WPA-PSK/WPA2-PSK |
| WPA Algorithm: TKIP | |
| Software | |
| Standard Version Parameter | RFC768 UDP |
| RFC791 IP | |
| RFC792 ICMP | |
| RFC793 TCP | |
| Channel Bandwidth: 20/40MHz (default) | |
| Working Mode | Repeater Mode (Client + AP) |
| Wireless Security | WPA-PSK/WPA2-PSK |
| DHCP Server | Supported |
| System Tools | Upgrade |
| Reset to Factory Default | |
| Login Password | |
| System Log | |
| Reboot | |
How to Reset?
To reset the Tenda A9, locate the RST Button on the extender device (see reference image below), then simply press and hold this button for about 8 seconds until the LED indicator turns solid red. Use something blunt like a pencil to press the button with.
How & Where to Buy?
To buy the Tenda A9 300Mbps Wi-Fi Range Extender, you can drop by our store (by appointment only) located at Novatel Communication, Main Street, Buttevant, Co. Cork P51 K066.
To purchase online, simply click on the Add to Cart button, and then go through the fast, easy, and secure checkout process. Payment is provided for your convenience via Stripe Payment Gateway. You can use any card supported by it (MasterCard, Visa, Amex, JCB, and more..).
How Will My Order Be Delivered?
Your order(s) will be shipped via express delivery and are normally delivered within 1-4 business days. Your order will be dispatched directly from our warehouse and you will be provided a piece of tracking information for your order after it is dispatched. If you have any questions about your order status, please contact us.
